Control the Led’s by using specific direction by magic light cup and mercury open optical module using Arduino Uno

Category: Arduino Compatible Kits Tags: Arduino Uno, Control the LEDs, magic light cup, mercury open optical module

Description
Reviews (0)

KIT INCLUDES:

HARDWARE REQUIRED

SOFTWARE REQUIRED

Arduino IDE

You can download it from this link: https://www.arduino.cc/en/Main/Software

PIN DESCRIPTION

MAGIC LIGHT CUP MODULE

Magic Light Cup modules are easy to Interactive Technology Division developed a can and ARDUINO interactive modules, PWM dimming principle is to use the principle of two modules brightness changes. Mercury switches provide a digital signal that triggers the PWM regulator, through the program design, We can see the light like two cups filled with the effect of shuffling back and forth.

– For Arduino DIY project
– Working Voltage: 5V
– Output: Digital output (0/1)
– PWM output
– Material: PCB
– Color: Black
– Dimensions: 0.91 x 0.79 x 0.59 inch / 2.3 x 2.0 x 1.5 cm

MERCURY OPEN OPTICAL TILT SWITCH MODULE

Operating voltage – 5v

Mercury switch module and a digital interface, built-in 13 LED build a simple circuit to produce tilt warning lamp 13 comes with digital interfaces of the LED, the mercury tilt switch sensor interface to access digital 3, when the tilt switch sensor senses a key signal, LED lights, otherwise off.

Arduino GND –> Pin – of module
Arduino 5+ –> Pin middel of module
Arduino 3 –> pin S of module

Tilt case

Non Tilt case

CIRCUIT DESCRIPTION

Connection the PIR Sensor to Arduino

first you connect the all sensors on bread board according to the given diagram and now
provide the all sensors power and gnd take from arduino to breadboard for common connection.
now connect the first module pin no 3&4 to arduino pin no 7 and 6.
now connect the second sensor pin no 3 to arduino uno pin no. 3 and connect the led with this sensor put 1 k resistance on positive point of led ,second point to ground.
now connect the third sensor module to pin no 3and 4 to arduino uno pin no5and 4 here is you connection complete of this circuit

CODE/strong>

CLICK TO SEE THE CODE:

https://docs.google.com/document/d/e/2PACX-1vS5t7eVIk2Igst7SWHvZmBguRv_5IfqG5GFyLy1RNWuZmtce7EGi87RkzAaBsRK-EJlm_YP2DcnLU9g/pub

OUTPUT

This is mercury tilt switch sensor these are the direction sensor uses in planes ,lift, many places.

In this sensor ,mercury in glass tube which provide the signals, it signals as blinking of led, if touch the another end of the sensor point.

This project have three sensor use for three type of working so how is it happen after the all connection we provide the supply to arduino uno now hold the bread board change the direction of the bread board you see the sensors light will change in three direction left,right,up direction use in a plain and then according the direction led’s will stated glowing.

By turning the Breadboard left side , led connected to Magic light cup module will turn on.
By turning the Breadboard right side , led connected to Magic light cup module will turn off.
By turning the Breadboard on up side , led connected to mercury optical tilt switch will turn on.
By turning the Breadboard on down side , led connected to mercury optical tilt switch will turn off.
