SOFTWARE REQUIRED

Name: Security system using Fingerprint sensor (GT-511C1R) and Arduino Uno
Brand: Robokreeda
SKU: 3430
Price: 4130 INR
Availability: InStock
Rating: 5 (1 reviews)

Arduino IDE 1.8.5 (programmable platform for Arduino)

Click To Download :https://www.arduino.cc/en/Main/Software

INSTALL LIBRARY

For servo Motor: inbuilt library of Arduino or Download from https://drive.google.com/drive/folders/1XEyFZik_ENYtE4LOf3mOP3kqfqH3FNh2

16*2 LCD Display (Liquid Display): inbuilt library of Arduino

GT511C fingerprint Scanner: Click on this link to download this library: https://drive.google.com/open?id=1g3E45sI85X5k6p8wPOYKOTOs_ST3xxJg

CIRCUIT CONNECTION

Connect the GT511 Fingerprint scanner to arduino with fingerprint scanner’s red wire to 3.3v of Arduino uno
Black wire of fingerprint scanner to arduino uno’s ground pin
Green wire of fingerprint scanner toarduino uno’s digital pin D7
White wire of Fingerprint scanner to Arduino’s digital pin D8

Download the code given in the link below:

CODE-1

Click to see the code or copy the link

https://goo.gl/Bqbh5C

#include <SoftwareSerial.h>

//need a serial port to communicate with the GT-511C1

SoftwareSerial gtSerial(8,7); // Arduino RX (GT TX), Arduino TX (GT RX)

void setup (){

Serial.begin(9600); //serial connection to processing app.

gtSerial.begin(9600); //for communicating with the GT-551C1

}

byte rx_byte=0; //stores recieved byte

void loop(){

if(Serial.available()){

//get byte from processing app. and send to FPS

rx_byte=Serial.read();

gtSerial.write(rx_byte);

}

//chech for a byte from the GT-511C1

if(gtSerial.available()){

//get a byte from thw FPS and send it to the processing app.

rx_byte=gtSerial.read();

Serial.write(rx_byte);

}

Now upload code 1

set the fingerprints using sdk software

Download the SDK Software:

https://learn.sparkfun.com/tutorials/fingerprint-scanner-hookup-guide?_ga=2.83121109.213978244.1515759134-440643312.1494316028

The image will be shown as given below:

when open as administrator then set com port and baud rate then enroll fingerprint upto 200 fingerprints as required.

Now connect the lcd to the breadboard
Connect pin 1 of LCD to ground
Connect pin 2 of LCD to positive rail on breadboard
Connect pin 3 of LCD to negative rail on breadboard
Connect pin 4 of LCD to digital pin 12 of arduino uno
Connect pin 5 of LCD to negative rail on breadboard
Connect pin 6 of LCD to pin 11 of arduino uno
Connect pin 11 of LCD to pin 5 of arduino uno
Connect pin 12 of LCD to pin 4 of arduino uno
Connect pin 13 of LCD to pin 3 of arduino uno
Connect pin 14 of LCD to pin 2 of arduino uno
Connect pin 15 of LCD to positive rail on breadboard
Connect pin 16 of LCD to negative rail on breadboard
Connect to breadboard with positive and negative rail
Connect a 100uf capacitor to the breadboard between Positive and negative rail
Now connect a servo motor
Connect orange wire of fingerprint scanner goes to pin 10 of arduino uno
Connect red wire to positive rail on breadboard and brown wire to negative rail on breadboard.

Now upload code 2

Click to download the code

CODE-2

Click to download the code or copy the link

https://goo.gl/5HWu9B

#include <Servo.h> // install from arduino’s library

#include <LiquidCrystal.h> // install from arduino’s library

#include “FPS_GT511C3.h”

#include “SoftwareSerial.h”

// Hardware setup – FPS connected to:

// digital pin 4(arduino rx, fps tx)

// digital pin 5(arduino tx – 560ohm resistor – fps tx – 1000ohm resistor – ground)

// this voltage divider brings the 5v tx line down to about 3.2v so we dont fry our fps

LiquidCrystal lcd(12, 11, 5, 4, 3, 2);

FPS_GT511C3 fps(8, 7);

Servo myServo;

void setup()

{

lcd.begin(16, 2);

lcd.clear();

Serial.begin(9600);

delay(1000);

fps.Open();

fps.SetLED(true);

myServo.attach(10);

}

void loop()

{

lcd.clear();

// Identify fingerprint test

if (fps.IsPressFinger())

{

fps.CaptureFinger(false);

int id = fps.Identify1_N();

if (id < 200)

{

lcd.print(“Welcome ID:”);

lcd.print(id);

delay(1000);

Serial.print(“Verified ID:”);

Serial.println(id);

myServo.attach(10);

myServo.write(0);

delay(2000);

myServo.detach();

delay(2000);

myServo.attach(10);

myServo.write(179);

delay(2000);

myServo.detach();

delay(2000);

}

else

{

lcd.clear();

lcd.print(“Finger not”);

lcd.setCursor(2, 1);

lcd.print(“found”);

delay(1000);

Serial.println(“Finger not found”);

}

else

{

lcd.clear();

lcd.print(“Please press”);

lcd.setCursor(2, 1);

lcd.print(“Finger”);

delay(1000);

Serial.println(“Please press finger”);

}

delay(100);

}

WORKING

In this security system using fingerprint sensor we used GT511C finger print sensor , in this we have to enroll the fingerprint using SDK software in this we can enroll up to 200 fingerprints. When we apply fingerprint

The gate will for the delay we provided and then it will close. The capacitor is used to reduce the spike voltage.
