Robokreeda MG90S Micro Servo Motor 9g (Metal Gear)

Name: Robokreeda MG90S Micro Servo Motor 9g (Metal Gear)
SKU: RK29058
Availability: InStock

₹188.80

High-quality all-metal-gear micro servo – perfect for robotics, RC airplanes, drones, pan-tilt cameras, and Arduino/Raspberry Pi projects.

Key Features

Full metal gears (upgraded from plastic) – super durable, no gear stripping
Operating Voltage: 4.8 V – 6.0 V
Torque: 2.0 kg·cm (4.8 V) / 2.5 kg·cm (6.0 V)
Speed: 0.11 sec/60° (4.8 V) / 0.09 sec/60° (6.0 V)
360° modifiable (easy mod for continuous rotation)
Stable double-ball-bearing design
Operating temperature: 0°C – 55°C
Lightweight: only 9 g
Standard 3-pin JR connector (VCC, GND, Signal)
Includes 4 types of servo horns + mounting screws

SKU: RK29058 Category: Electronics Components

Description
Reviews (0)

Robokreeda MG90S Micro Servo Motor 9g (Metal Gear)

High-quality all-metal-gear micro servo – perfect for robotics, RC airplanes, drones, pan-tilt cameras, and Arduino/Raspberry Pi projects.

Key Features

Full metal gears (upgraded from plastic) – super durable, no gear stripping
Operating Voltage: 4.8 V – 6.0 V
Torque: 2.0 kg·cm (4.8 V) / 2.5 kg·cm (6.0 V)
Speed: 0.11 sec/60° (4.8 V) / 0.09 sec/60° (6.0 V)
360° modifiable (easy mod for continuous rotation)
Stable double-ball-bearing design
Operating temperature: 0°C – 55°C
Lightweight: only 9 g
Standard 3-pin JR connector (VCC, GND, Signal)
Includes 4 types of servo horns + mounting screws

Technical Specifications

Dimensions: 22.8 × 12 × 29.4 mm
Weight: 9 g
Stall Current: ~750 mA @ 6 V
Deadband: 5 µs
Cable Length: 25 cm

Applications

Mini quadcopters & RC planes
Robot arms & grippers
Pan-tilt camera mounts
Steering on small RC cars/boats
Animatronics & DIY projects

Package Includes

1 × Robokreeda MG90S Metal Gear Servo
1 × Single-arm horn
1 × Double-arm horn
1 × Four-point horn
1 × Circular horn
Mounting screws & rubber grommets

Tiny size, mighty strength — the Robokreeda MG90S is the go-to metal-gear micro servo trusted by thousands of makers!
